Technical Specifications
-
SUN-60K-G04P3-EU-AM4
- SUN-70K-G04P3-EU-AM4
- SUN-75K-G04P3-EU-AM4
- SUN-80K-G04P3-EU-AM4
- Feedback
| Model | SUN-60K-G04P3-EU-AM4 | SUN-70K-G04P3-EU-AM4 | SUN-75K-G04P3-EU-AM4 | SUN-80K-G04P3-EU-AM4 |
| PV String Input Date | ||||
| Max. PV Input Power(kW) | 90 | 105 | 112.5 | 120 |
| Max. PV Input Voltage(V) | 1100 | |||
| Start-up Voltage(V) | 250 | |||
| MPPT voltage range(V) | 200-1000 | |||
| Rated PV Input voltage(V) | 600 | 720 | ||
| Max. Input Short Circuit Current (A) | 60+60+60+60 | |||
| Max. Operating PV Input Current(A) | 40+40+40+40 | |||
| No. of MPP Trackers/ No. of Strings MPP Tracker |
4/3+3+3+3 | 4/4+4+4+4 | ||
| AC Output Side | ||||
| Rated AC Output Active Power (kW) | 60 | 70 | 75 | 80 |
| Max. AC Output Apparent Power (kVA） | 66 | 77 | 82.5 | 88 |
| Rated AC Output Current (A) | 90.9/87 | 106.1/101.5 | 113.6/108.7 | 121.2/115.9 |
| Max. AC Output Current (A) | 100/95.7 | 116.7/111.6 | 125/119.6 | 133.3/127.5 |
| Rated Output Voltage/Range (V） | 220/380V, 230/400V 0.85Un-1.1Un | |||
| Grid Connection Form | 3L+N+PE | |||
| Rated Output Grid Frequency/range(Hz) | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz | |||
| Power Factor Adjustment Range | 0.8 leading to 0.8lagging | |||
| Total Current Harmonic Distortion THDi | <3% | |||
| DC Injection Current | <0.5%ln | |||
| Efficiency | ||||
| Max. Efficiency | 98.60% | 98.70% | ||
| Euro Efficiency | 98.00% | 98.10% | ||
| MPPT Efficiency | ＞99% | |||
| Equipment Protection | ||||
| DC Polarity Reverse Connection Protection | yes | |||
| AC Output Overcurrent Protection | yes | |||
| AC Output Overvoltage Protection | yes | |||
| AC Output Short Circuit Protection | yes | |||
| Thermal Protection | yes | |||
| DC Terminal Insulation Impedance Monitoring | yes | |||
| DC Component Monitoring | yes | |||
| Ground Fault Current Monitoring | yes | |||
| Arc Fault Circuit Interrupter (AFCI) | Optional | |||
| Power Network Monitoring | yes | |||
| Island Protection Monitoring | yes | |||
| Earth Fault Detection | yes | |||
| Overvoltage Load Drop Protection | yes | |||
| Residual Current (RCD) Detection | yes | |||
| Surge Protection Level | TYPE II(DC),TYPE II(AC) | |||
| Interface | ||||
| Communication Interface | RS485/RS232 | |||
| Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) | |||
| General Data | ||||
| Operating Temperature Range (°C) | -25 to +60℃, >45℃ Derating | |||
| Permissible Ambient Humidity | 0~100% | |||
| Permissible Altitude (m) | 4000m | |||
| Noise (dB) | ≤ 55 | |||
| Ingress Protection(IP) Rating | IP 65 | |||
| Inverter Topology | Non-Isolated | |||
| Over Voltage Category | OVC II(DC),OVC III(AC) | |||
| Cabinet Size (WxHxD mm) | 698×613×236.5 (Excluding Connectors and Brackets) | |||
| Weight [kg] | 53.7 | |||
| Warranty [year] | 5 years | |||
| Type Of Cooling | Intelligent air cooling | |||
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
|||
| Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |||
